BLADES FOR CONSTRUCTION AND FIREWOOD CUTTING
Nome Serie:
286
Click to enlarge images
TECHNICAL CHARACTERISTICS OF HW TEETH:
| -tooth height in mm: | 6~10 |
| -quality, ISO code: | K20 |
| -hardness (HV10): | 1.550 |
| -flexural strength (N/mm2): | 2.600 |
COMBI3 driving holes: 2/7/42 + 2/9,5/46,5 + 2/10/60.
Suggestions: We recommend the purchase of the reduction from 30mm to 25mm (code 299.225.00) for blades Ø250-300-315 and the purchase of the reduction from 30mm to 25mm (code 299.228.00) for blades Ø350 and above.
Application
Use: for long and vein cuts. Particularly suitable in the building sector.
Machines: table saws, mitre saws and portable hand feed machines.
Material: soft and hard woods, panels with nails, metal staples and concrete.
| Product | Product | Price | Buy | D | F | FT | Z | K | P | a | b | Favorites |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 286.016.10M | 286.016.10M | 29,60 € | 250 | 30 | COMBI3 | 16 | 2,8 | 1,8 | 15° | 5° ATB | ||
| 286.020.12M | 286.020.12M | 37,53 € | 300 | 30 | COMBI3 | 20 | 2,8 | 1,8 | 15° | 5° ATB | ||
| 286.024.13M | 286.024.13M | 37,53 € | 315 | 30 | COMBI3 | 24 | 3,2 | 2,2 | 15° | 5° ATB | ||
| 286.024.14M | 286.024.14M | 43,76 € | 350 | 30 | COMBI3 | 24 | 3,2 | 2,2 | 15° | 5° ATB | ||
| 286.028.16M | 286.028.16M | 55,44 € | 400 | 30 | COMBI3 | 28 | 3,2 | 2,2 | 15° | 5° ATB | ||
| 286.032.18M | 286.032.18M | 72,66 € | 450 | 30 | 2/10/60 | 32 | 3,8 | 2,8 | 15° | 5° ATB | ||
| 286.036.20M | 286.036.20M | 102,15 € | 500 | 30 | 2/10/60 | 36 | 3,8 | 2,8 | 15° | 5° ATB | ||
| 286.040.22M | 286.040.22M | 116,01 € | 550 | 30 | 2/10/60 | 40 | 4,2 | 3,2 | 15° | 5° ATB | ||
| 286.040.24M | 286.040.24M | 125,39 € | 600 | 30 | 2/10/60 | 40 | 4,2 | 3,2 | 15° | 5° ATB | ||
| 286.046.28M | 286.046.28M | 174,22 € | 700 | 30 | 2/10/60 | 46 | 4,4 | 3,2 | 15° | 5° ATB |
*All the prices include 22% Italian VAT
